Final Graphics Post!

This is the last post in this segment of blogs! I will be doing an overview of the material we went over in this class. So lets get right to it.

We learned about shaders and shaders are small programs in the graphics pipeline that give more freedom to the original graphics pipeline. We have three main shaders that we covered in this course, Vertex Shader, Geometry Shader, and Fragment Shader.

The Vertex Shader takes in vertices along with other attributes and uniforms. Then the program does whatever the programmer likes but they usually manipulate the placement of the vertices in a scene. They then output the vertices along with their attributes.

Next in the pipeline is primitive assembly, this is where the triangles are formed and those are passed to the Geometry Shader. The Geometry Shader is used to add geometry to already existing geometry which is mainly used for tessellation  The output would be more vertices or other geometry. This is now passed to our good friend the Rasterizer who gives pixels to our geometry. The shapes use tri linear interpolation between the vertices of the triangles to assign data to each pixel.

The Fragment Shader retrieves these pixels along with the uniforms and any attributes. Then inside the shader is up to the programmers discretion but they are normally manipulating the color of the pixels. The output then would be color of the fragments.

An often used tool with shaders is a frame buffer object or an FBO. There are also vertex buffer objects and vertex array objects or VBO's and VAO's. These are just sources of memory that are either samples of the screen as a texture or an array of vertices for an object.

Now we also went over many different algorithms and shaders during the course of the semester. Here is a list of the different shader techniques:
-Lighting
-Blur/Motion Blur
-Bloom/HDR
-Toon Shading
-Shadow Mapping
-Deferred Rendering
-Mesh Skinning
-Normal Mapping

There are four different types of lighting: Diffuse, Ambient, Emissive, and Specular. Diffuse lighting requires normals and is calculated by the dot product of the normal vector of a vertex and the vector from the light to the vertex. Ambient is the color of the light. Emissive lighting is the light coming from an object. Specular lighting is calculated by the dot product of the vector from the light to the vertex by the relfected ray vector.

With blur there are two different types we learned, Box and Gaussion. They are done by sampling neighboring pixels and blending them together. Box has uniform weights around the pixel being sampled and Gaussian has a gradient fall off on the weights. The sum of the weights equal 1. There can be an added bright pass which illuminates bright pixels more and makes dark ones darker. Motion blur is done by accumulating frames and blending them together.

Toon Shading is done by sampling from a blocky gradient and applying the level of light to certain gradients. If the level falls into a certain level then use that sample.

Shadow Mapping refers to the depth buffer or Z buffer relative to the light source. It creates a vector from the light to the depth buffer. From the camera perspective we send the position of the fragment in question to the shader. Then we create a vector from that pixel and light and check, if the depth vector is less than the pixel vector, draw that pixel grey, else draw normally.

Deferred rendering is to optimize calculations that forward rendering does. We use this to be able to use several lights in a single scene. Way more can be said about this but my understanding currently is still weak about it.

Mesh Skinning is mainly used in the vertex shader as we are manipulating the vertices of the object being drawn. With mesh skinning, we can deform the skin of a model relative to the weights assigned by an artist to the joints in the skeleton.

Normal Mapping is used to make low poly models look like high poly models. This is done by sampling the normals of the high poly model and applying them to the fragments of the low poly model. There are two different types of normal mapping, object and tangent space normal mapping. Object is relative to the object being normal mapped and tangent is relative to the tangent space of the normal map.

Honorable mention goes out to Displacement mapping as we discussed it but rarely went into depth about it.

This wraps up our class of Intermediate Computer Graphics, I learned so much about this class and enjoyed it so much.

Motion Blur

This week's blog is going to go over a simple shader that gives the effect of motion blur! So allow me to give a brief explanation of what motion blur is. Motion blur is the streaking of rapidly moving objects in a still image or a sequence of images such as a movie or animation. This happens when the image being recorded changes during the recording of a single frame, either due to rapid movement or long exposure. As you can see in the photo above, this is not the case. The reason why you can tell is because according to the definition of motion blur, everything moving in the image would be blurred. There is lots of places in the image that are very in focus, this means that the photo was taken and it was perfectly clear. Then someone took it into photoshop and applied blur to it in specific spots.

Now remember what we know about photoshop and shaders, that everything you can do in photoshop can be programmed into a shader! First you might be asking yourself, why would we even want this? Most time people are trying to get rid of motion blur in their photos and videos. Everyone's looking for crystal clear imaging nowadays so why add motion blur? We would add this motion blur to games because we are looking to add a sense of realism to the game. This kind of blur occurs naturally and therefore, makes a games graphics look more natural.

Here is another image that demonstrates good motion blur. This could have actually been the raw image since all the static objects in the scene are in focus while the moving objects have motion blur on them.

I found this image while searching for good motion blur photos for this blog. Thought it was funny so I shall share it.

Now below is the difference between having motion blur in games and not.  As you can see, when motion blur is off it looks good because the graphics in general are alright. The difference motion blur makes on the left image be more natual and visually appealing.

This effect can easily be applied in photoshop with a large arsenal of tools at the developers disposal.There are all sorts of blurs and they even have a nice motion blur tool such as the one below.

Here the developer has access to the angle of motion blur and how far the blur will streak. When programming this tool, we can give the same controls to the developer. To start, the angle of blur will be dynamic. So no matter which way the objects are moving they will cause blur in the direction they are moving. Now, if this wasn't the desired effect or you wanted to constrain the areas where objects have motion blur, then these conditions will be covered with conditional statements on the CPU side of things. As for the amount of blur or the distance in which the image will be blurred, that is controlled by how many frames we add together for the blurring effect.

When it comes to the actual programming of this, there are many different ways it can be done. The first way I'm going to cover is all done entirely on the CPU using an OpenGl function called glAccum. Now what we are going to do with this is we are going to store a certain number of frames into an accumulation buffer. The amount is up to how much blur we want to have. Then we will check to see if we have accumulated enough frames and once we have then will blend them together and reset the frame counter and draw. This is a slow but extremely simple way of doing it. http://www.cse.msu.edu/~cse872/tutorial5.html A link is provided if you are interested in seeing line by line how it works.

The other way to do this is on the GPU side in shaderland. This way is a little more annoying but it is still fairly simple. So what we are going to do here is manually do what we did on the CPU but instead have it occur on the GPU processed in a fragment shader. We are going to need those frames though. Let's use our favourite tool, FBO's, and let's use a bunch. We will take about five of them, yeah that should be good. We will slap four frames from the screen onto four of the five framebuffers. Now lets send these textures through the pipeline and put that fragment shader to work. We're going to have the shader mix all of the frames together and return one final fully blended version. This will give the bluring effect we need when an object moves. We would still apply the same logic as we had on the CPU. There are even more efficient ways of creating motion blur than that but those are two different ways it can be done.
